We started the development of capacitors with large capacitance and for high ripple current, ahead of other companies. Now, our capacitors for mid- to high-voltage have a high market share. Our Screw Terminal Type Aluminum Electrolytic Capacitors are used for inverters for trains and elevators etc. in the fields that are required to offer high reliability.
Features
• Through the self-development of high-quality anode foil and electrolyte, high reliability and excellent cost performance have been achieved.
• Our products are used for the equipment that requires a large capacitance such as inverter and large power source.
• Lead-free/Conforming to RoHS Directive

HCGFA2W271_A053  270uF 450V

HCGFA2W331_A083  330uF 450V

HCGFA2W391_A083  390uF 450V

HCGFA2W471_A083  470uF 450V

HCGFA2W561_A100  560uF 450V

HCGFA2W681_A100  680uF 450V

HCGFA2W821_C075  820uF 450V

HCGFA2W102_C075  1000uF 450V

HCGFA2W122_C096  1200uF 450V

HCGFA2W152_C115  1500uF 450V

HCGFA2W182_C130  1800uF 450V

HCGFA2W222_D096  2200uF 450V

HCGFA2W222_E103  2200uF 450V

HCGFA2W272_D115  2700uF 450V

HCGFA2W332_E115  3300uF 450V

HCGFA2W332_D130  3300uF 450V

HCGFA2W332_E143  3300uF 450V

HCGFA2W372_E105  3700uF 450V

HCGFA2W392_E115  3900uF 450V

HCGFA2W472_E130  4700uF 450V

HCGFA2W562_E155  5600uF 450V

HCGFA2W682_F145  6800uF 450V

HCGFA2W682_F157  6800uF 450V

HCGFA2W822_F157  8200uF 450V

HCGFA2W103_F145  10000uF 450V

HCGFA2W103_F196  10000uF 450V

HCGFA2W123_F236  12000uF 450V

FXA 3900MFD 450VDC HCGFA2W392-E115 FXR2W222Y 2200MFD 450VDC HCGF5A 10000MFD 400VDC HCGFA 1000MFD 450V HCGFA 1000uF 400VDC HCGFA 1000uF 450VDC HCGFA 1800MFD 450V HCGFA 33000MF 50VDC HCGFA 33000MFD 16VDC HCGFA 6800MFD 450VAC
