We started the development of capacitors with large capacitance and for high ripple current, ahead of other companies. Now, our capacitors for mid- to high-voltage have a high market share. Our Screw Terminal Type Aluminum Electrolytic Capacitors are used for inverters for trains and elevators etc. in the fields that are required to offer high reliability.
Features
• Through the self-development of high-quality anode foil and electrolyte, high reliability and excellent cost performance have been achieved.
• Our products are used for the equipment that requires a large capacitance such as inverter and large power source.
• Lead-free/Conforming to RoHS Directive

HCGFA2W271_A053  270uF 450V

HCGFA2W331_A083  330uF 450V

HCGFA2W391_A083  390uF 450V

HCGFA2W471_A083  470uF 450V

HCGFA2W561_A100  560uF 450V

HCGFA2W681_A100  680uF 450V

HCGFA2W821_C075  820uF 450V

HCGFA2W102_C075  1000uF 450V

HCGFA2W122_C096  1200uF 450V

HCGFA2W152_C115  1500uF 450V

HCGFA2W182_C130  1800uF 450V

HCGFA2W222_D096  2200uF 450V

HCGFA2W222_E103  2200uF 450V

HCGFA2W272_D115  2700uF 450V

HCGFA2W332_E115  3300uF 450V

HCGFA2W332_D130  3300uF 450V

HCGFA2W332_E143  3300uF 450V

HCGFA2W372_E105  3700uF 450V

HCGFA2W392_E115  3900uF 450V

HCGFA2W472_E130  4700uF 450V

HCGFA2W562_E155  5600uF 450V

HCGFA2W682_F145  6800uF 450V

HCGFA2W682_F157  6800uF 450V

HCGFA2W822_F157  8200uF 450V

HCGFA2W103_F145  10000uF 450V

HCGFA2W103_F196  10000uF 450V

HCGFA2W123_F236  12000uF 450V

FXR2W222Y 2200MFD 450VDC HCGF3A 1000MFD 400VDC HCGF5A 10000MFD 400VDC HCGFA 1000MFD 450V HCGFA 1000uF 400VDC HCGFA 1000uF 450VDC HCGFA 1800MFD 450V HCGFA 1800uF 450VDC HCGFA 33000MFD 16VDC HCGFA 3300MFD 450VDC
