MITSUBISHI INTELLIGENT POWER MODULES
FLAT-BASE TYPE
INSULATED PACKAGE

Description:
Mitsubishi Intelligent Power Modules are isolated base modules designed for power switching applications operating at frequencies to 20kHz. Built-in control circuits provide optimum gate drive and protection for the IGBT and free-wheel diode power devices.

Features:
• Complete Output Power Circuit
• Gate Drive Circuit
• Protection Logic
—Short Circuit
—Over Current
—Over Temperature
—Under Voltage

Applications:
• Inverters
• UPS
• Motion/Servo Control
• Power Supplies

PM10CNA060 PM150RSE120 PM300SJ060 PM30RSF060 PM400DVA060 PM50RHB060-1 PM75CSD120 PS12012 PS12034-Y2S59AA6 PS21964-4S
