MITSUBISHI INTELLIGENT POWER MODULES
FLAT-BASE TYPE
INSULATED PACKAGE

Description:
Mitsubishi Intelligent Power Modules are isolated base modules designed for power switching applications operating at frequencies to 20kHz. Built-in control circuits provide optimum gate drive and protection for the IGBT and free-wheel diode power devices.

Features:
• Complete Output Power Circuit
• Gate Drive Circuit
• Protection Logic
—Short Circuit
—Over Current
—Over Temperature
—Under Voltage

Applications:
• Inverters
• UPS
• Motion/Servo Control
• Power Supplies
