MOT Hybrid Power Module
Integrated Power Stage for Motor Drives
This module integrates a 3–phase inverter, 3–phase rectifier,
brake, and temperature sense in a single convenient package. It is
designed for 5.0 hp general purpose 3–phase induction motor drive
applications. The inverter incorporates advanced insulated gate
bipolar transistors (IGBT) matched with fast soft free–wheeling
diodes to give optimum performance. The solderable top connector
pins are designed for easy interfacing to the user’s control board.
• Short Circuit Rated 10 µs @ 125°C, 720 V
• Pin-to-Baseplate Isolation Exceeds 2500 Vac (rms)
• Compact Package Outline
• Access to Positive and Negative DC Bus
• Independent Brake Circuit Connections
• UL Recognition Pending
